Mosquito Dowel Bits HW

Product

Drawing

  • Tungsten Carbide [HW]
  • MAN

Article

Description

Machine / Application

  • portable boring machines
  • automatic boring machines
  • CNC machining centers
  • for chip-free drilling of dowel holes in solid woods and wood-based panels

Design

  • special cutting edge geometry
  • 2 spurs
  • centering point
  • HW-tipped

Advantages

  • chip-free hole edges thanks to special cutting edge geometry with spurs
  • safe drilling thanks to centering point
  • high process safety thanks to constant quality of the bores for a long time
  • tool life increased up to sixfold compared to traditional dowel bits thanks to wear-resistant HW plunging tip

Notes

  • adjusting screw Ident-No. 001600 M5x10 DIN 551 for precise length adjustment included in delivery
  • adjusting screw Ident-No. 186017 M5x11,5 for Weeke quick clamping chuck must be ordered separately
  • clamping elements: combi chuck, quick-change chuck

Table- and picture caption ...

Ø D
[mm] 		L2
[mm] 		Ø d
[mm] 		L3
[mm] 		L1
[mm] 		Z L/R Ident-No. Comp./ Inqu.

Dimensions entered are not listed?
Please contact our application consulting .

available from stock
available on short notice
Delivery time on request

5 25 10 27 57.5 2+2 L 181168
|
5 25 10 27 57.5 2+2 R 181167
|
6 25 10 27 57.5 2+2 L 181522
|
6 25 10 27 57.5 2+2 R 181521
|
7 27 10 27 57.5 2+2 R 183158
|
7 27 10 27 57.5 2+2 L 183159
|
8 25 10 27 57.5 2+2 L 181170
|
8 25 10 27 57.5 2+2 R 181169
|
9 27 10 27 57.5 2+2 R 183160
|
9 27 10 27 57.5 2+2 L 183161
|
10 25 10 27 57.5 2+2 L 181524
|
10 25 10 27 57.5 2+2 R 181523
|
5 35 10 30 70 2+2 L 181172
|
5 35 10 30 70 2+2 R 181171
|
6 35 10 30 70 2+2 L 181526
|
6 35 10 30 70 2+2 R 181525
|
7 35 10 30 70 2+2 R 183162
|
7 35 10 30 70 2+2 L 183163
|
8 35 10 30 70 2+2 L 181174
|
8 35 10 30 70 2+2 R 181173
|
9 35 10 30 70 2+2 R 183164
|
9 35 10 30 70 2+2 L 183165
|
10 35 10 30 70 2+2 L 181528
|
10 35 10 30 70 2+2 R 181527
|
