Dowel Bits HW - with back-guide

Product

Drawing

  • Tungsten Carbide [HW]
  • MAN

Article

Description

Machine / Application

  • portable boring machines
  • automatic boring machines
  • CNC machining centers
  • for chip-free drilling of dowel holes in solid woods and wood-based panels

Design

  • 2 negative spurs
  • centering point
  • spiral with back-guide
  • plastic coated
  • HW-tipped

Advantages

  • chip-free hole edges thanks to spurs
  • safe drilling thanks to centering point
  • protection of the hole edge upon exiting thanks to spiral with back guide
  • optimum chip evacuation thanks to plastic coating

Notes

  • adjusting screw: Ident-No. 001600 M5x10 DIN 551 for precise length adjustment
  • adjustable countersink attachment on the boring spiral for simultaneous chamfering of the hole
  • shell countersink Class-No. 130660
  • clamping element: combi chuck, quick-change chuck

Table- and picture caption ...

Ø D
[mm] 		L2
[mm] 		Ø d
[mm] 		L3
[mm] 		L1
[mm] 		Z L/R Ident-No. Comp./ Inqu.

Dimensions entered are not listed?
Please contact our application consulting .

available from stock
available on short notice
Delivery time on request

4 30 8,0 19 55.5 2+2 L 166107
|
4 30 8,0 19 55.5 2+2 R 166106
|
5 30 8,0 19 55.5 2+2 L 011543
|
5 30 8,0 19 55.5 2+2 R 011542
|
6 30 8,0 19 55.5 2+2 L 054884
|
6 30 8,0 19 55.5 2+2 R 054883
|
8 30 8,0 19 55.5 2+2 L 054892
|
8 30 8,0 19 55.5 2+2 R 054891
|
10 30 8,0 19 55.5 2+2 L 054896
|
10 30 8,0 19 55.5 2+2 R 054895
|
12 30 8,0 20 55.5 2+2 L 166113
|
12 30 8,0 20 55.5 2+2 R 166112
|
4 40 8,0 19 67 2+2 R 167154
|
5 40 8,0 19 67 2+2 L 057494
|
5 40 8,0 19 67 2+2 R 057493
|
6 40 8,0 19 67 2+2 L 057496
|
6 40 8,0 19 67 2+2 R 057495
|
7 40 8,0 19 67 2+2 L 167167
|
7 40 8,0 19 67 2+2 R 167157
|
8 40 8,0 19 67 2+2 L 057498
|
8 40 8,0 19 67 2+2 R 057497
|
9 40 8,0 19 67 2+2 L 167169
|
9 40 8,0 19 67 2+2 R 167159
|
10 40 8,0 19 67 2+2 L 057500
|
10 40 8,0 19 67 2+2 R 057499
|
12 40 8,0 19 67 2+2 L 167172
|
12 40 8,0 19 67 2+2 R 167162
|
5 30 10 19 57.5 2+2 L 167184
|
5 30 10 19 57.5 2+2 R 167174
|
6 30 10 20 57.5 2+2 L 167185
|
6 30 10 20 57.5 2+2 R 167175
|
7 30 10 20 57.5 2+2 L 167186
|
7 30 10 20 57.5 2+2 R 167176
|
8 30 10 20 57.5 2+2 L 167187
|
8 30 10 20 57.5 2+2 R 167177
|
10 30 10 20 57.5 2+2 L 167188
|
10 30 10 20 57.5 2+2 R 167178
|
12 30 10 20 57.5 2+2 L 167189
|
12 30 10 20 57.5 2+2 R 167179
|
13 30 10 20 57.5 2+2 L 167190
|
13 30 10 20 57.5 2+2 R 167180
|
14 30 10 20 57.5 2+2 L 167191
|
14 30 10 20 57.5 2+2 R 167181
|
15 30 10 20 57.5 2+2 L 167192
|
15 30 10 20 57.5 2+2 R 167182
|
16 30 10 20 57.5 2+2 L 167193
|
16 30 10 20 57.5 2+2 R 167183
|
5 43 10 20 70 2+2 L 167203
|
5 43 10 19 70 2+2 R 167194
|
6 43 10 20 70 2+2 L 167204
|
6 43 10 19 70 2+2 R 167195
|
8 43 10 20 70 2+2 L 167205
|
8 43 10 19 70 2+2 R 167196
|
9 43 10 20 70 2+2 L 167206
|
9 43 10 19 70 2+2 R 167197
|
10 43 10 20 70 2+2 L 167207
|
10 43 10 19 70 2+2 R 167198
|
12 43 10 20 70 2+2 L 167208
|
12 43 10 19 70 2+2 R 167199
|
